Your tent, our membrane. VALMEX® tent stands for versatility. From highly translucent to fully opaque, from light to heavy, from white to black, from pagoda to two-storey tent system and from commercial tent to circus tent, everything is possible. Manufactured using specially selected materials, the VALMEX® tent products comply with the highest standards with respect to UV, fungal and fire resistance. The acrylic coating on both sides is the perfect finishing touch, ensuring good resistance to dirt and easy cleaning, as well as durability.

The lightweight all-rounder

VALMEX® FR 580 is a high-quality technical textile for various applications, primarily permanent and temporary tensioned structures, tents and sun shading. The material is treated with fungicide and UV stabilising agents, and is certified as flame-retardant under multiple national standards. Our standard portfolio for this high-quality textile boasts an impressive range of colours.

  • Weldable
  • Opaque
  • Translucent
  • Weatherproof
  • UV-resistant
  • Antimicrobial
  • Stain-resistant
  • Water repellent
article number 7219-5240

Product specifications for VALMEX® TENT | FR 580

Material propertiesValueUnitMeasuring Methods/NormRemark
Total weight580g/m²EN ISO 2286-2
Tensile strength warp/weft2700 / 2900N/50 mmEN ISO 1421/V1
Tear strength warp/weft300 / 300NDIN 53363
Adhesion20N/cmPA 09.03 (intern)
Cold resistance.-40°CEN 1876-1
High Temperature+70°CPA 07.04 (intern)
Light fastness>6Note, ValueEN ISO 105 B02
Crack resistance100000 xDIN 53359 Ano cracks
MaterialPESDIN EN ISO 2076
Yarn count1100dtexDIN EN ISO 2060
WeaveL 1/1ISO 3572
Type of coatingPVC
Finishboth sides lacquered, high gloss, antimicrobial, UV-protected
Burning behaviourD.M. 26.06.84 (UNI 9177): CL. 1, California T 19, ASTM E 84 Class A, NFPA 701 Test 2, NFP 92507: M2 (Coloris divers), NFP 92507: M2, AS 1530 part 2, AS 1530 part 3, CPAI 84, EN 13501-1: B-s3-d0, DIN 4102: B1
for Burning behaviouralways check validity of fire certificate, also check country-specific validity
All technical data set out above are for product information purposes only and not legally binding, and will cease to apply with any further development of the products. The most recent technical data will be provided by Low & Bonar on request. Please note that the technical data as set out above are average values only. All values are generated through tests by established laboratories in accordance with industry standards. Results may vary if testing is executed by different laboratories or due to different standard interpretation. All technical data apply to new products only. Deviations may occur due to production procedures.

This product is available in the following colors:

  • Natur Beige 112 Natur Beige
  • Brilliantgelb 114 Brilliantgelb
  • Perlweiß 141 Perlweiß
  • Burgund 371 Burgund
  • Hellblau 517 Hellblau
  • Blau 572 Blau
  • Hollandgrün 636 Hollandgrün
  • Lichtgrau 724 Lichtgrau
  • Beigerot 842 Beigerot
  • Schwarz 905 Schwarz
  • Superweiß 958 Superweiß
All pictured colors are digitally reconstructed according to the color of the tarpaulins. Due to the reproduction, the color representation is not binding and may differ from the original depending on you browser and screen. We therefore recommend to order samples in the desired colors from us.
